MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital
MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital

MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital

Product Details:
Place of Origin: Guangdong, China
Brand Name: flysafe
Model Number: MK32
Payment & Shipping Terms:
Minimum Order Quantity: 1
Delivery Time: 5-8 work days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Contact Now

Detail Information
Max Transmission Range: 15 Km (unobstructed, Free Of Interference) Link Features: An All-In-One Link Integrated With Remote Control, Datalink, And Video Streaming 1080p Full HD Dual Low-latency Digital Image Transmission
Air Unit Video Input: Ethernet Air Unit Voltage Input: 3S To 6S (expandable To 18S Through BEC)
Channels: 16 Physical Channels 16 Communication Channels Monitor: 7-inch High Definition And High Brightness LCD Touchscreen
System: Android 9.0 OS 4G RAM 64G ROM Battery Life: 10 Hours
Dimensions (Antenna Overlapped): 308 X 148 X 72 Mm Weight (Antenna Overlapped): 1440 G
Highlight:

HD High Brightness Ground Station

,

MK32 Enterprise Ground Station

,

7-Inch Ground Station

Product Description

Product Description

MK32 enterprise handheld ground station is the latest member of the family of SIYI links. It  carries a 7-inch high-definition and high brightness monitor, and a dual way full HD image transmission system which can be expanded to up to 30 kilometers range. MK32’s Android system is  upgraded to 4G RAM and 64G ROM. Optional combos of MK32 system can have dual operator  and RC relay feature. MK32’s abundant features and powerful performance make it a commonly  used equipment of smooth image transmission, stable datalink, and solid control for UAV commercial drones, UGV unmanned vehicles, USV unmanned boats, and robotics.

Technical Specification

Monitor7-inch High Definition and High Brightness LCD Touchscreen
System

Android 9.0 OS

4G RAM, 64G ROM

Battery Capacity & Type

10200 mAh 7.4V 2S Li-ion

75.48 Wh

Fast Charging ProtocolPD 30W
Charging Time3.5 hours (PD 30W)
Battery Life10 hours
Antenna Gain

Omni Antenna: 5 dBi

Long Range Antenna: 11 dBi

Lollipop Antenna: 5 dBi (optional)

Dimensions (Antenna Overlapped)308 x 148 x 72 mm
Weight (Antenna Overlapped)1440 g
Waterproof LevelIP4X
Working Temperature-10℃ ~ 50℃

MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital 0

MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital 1

MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital 2

MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital 3

MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital 4

MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital 5

MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital 6

MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital 7

MK32 Enterprise 7-Inch HD High Brightness LCD Touchscreen Handheld Ground Station Smart Controller Dual Full HD Digital 8
