Circular Polarization Omni Wifi Anti Drone Antenna 50W 800MHz-1620MHz
Product Details:
|
|
Place of Origin: | Guangdong, China |
---|---|
Brand Name: | flysafe |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1 |
Price: | Negotiable |
Delivery Time: | 5-8 work days |
Payment Terms: | LC,T/T,MoneyGram,Western Union,D/P,D/A,L/C |
Detail Information |
|||
Frequency Range: | Frequency Range 2400-2500 MHz | Antenna Weight(kg): | 0.136KG |
---|---|---|---|
Dimensionsmm(Height/Width/Depth): | Diameter32*149mm | Maximum Input Power(W): | 50W |
Highlight: | Omnidirectional Anti Drone Antenna,3dbi Anti Drone Antenna,2.4GHz high gain omni antenna |
Product Description
700-1050MHZ 3.5dBi Black Fatty Omni Antenna is an innovative product designed for the shortcomings of Comans fiberglass antenna, such as high energy consumption, which combines the performance of the classic Broden antenna, wider antenna, higher sensitivity, better heat dissipation, widely used in many kinds of drone signal jammers, the customer can choose the right one according to the actual situation. frequency band. Compared with traditional antennas, it has the same weight and higher power. We provide personalized customization, such as range band 700-1050MHz, gain 3.5±0.5dBi, length 23.5cm, achieving high power and low consumption.
Electrical Specifications
|
||
Frequency Range
|
2400-2500 MHz
|
|
Gain(dBi)
|
3±0.5dBi
|
|
VSWR
|
≤1.5
|
|
Polarization
|
vertical
|
|
Horizontal Beamwidth(0º)
Vertical Beamwidth(0º) |
360º
55±5º |
|
ovality(dB)
|
≤±2dB
|
|
Input Impedance(Ω)
|
50Ω
|
|
Maximum input power(W)
|
50W
|
|
Input connector type
|
N-K
|
|
Lightning Protection
|
DC Ground
|
|
MechanicalSpecifications
|
||
Dimensions­mm(Height/Width/Depth)
|
ɸ32*149mm
|
|
Antenna weight(kg)
|
0.136KG
|
|
Rated Wind Velocity(m/s)
|
60m/s
|
|
Operational Humidity(%)
|
10- 95
|
|
Radome Color
|
black
|
|
Radome material
|
glass fiber reinforced plastics
|
|
Operating temperature(ºC)
|
-40~55º
|
|
Installation Method
|
Machine installation
|
