400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection

Product Details

Place of Origin: Guangdong, China

Brand Name: flysafe

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiable

Delivery Time: 7-15 work days

Payment Terms: LC, T/T

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                5800MHz Signal Jammer Module, Power Amp Signal Jammer Module, 400MHz power amp module


Frequency:	400-5800MHZ(Customized)	Size:	1795020mm
Weight:	294g

Frequency:	400-5800MHZ(Customized)
Size:	1795020mm
Weight:	294g

400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection

400-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection

Product Description

This is a 400-5800MHz 50W amplifier module with temperature protection. This high performance 400-5800MHz 50W amplifier module is a cutting edge solution for enhancing signal strength in a variety of applications. The temperature protected 400-5800MHz 50W amplifier module has a frequency range of 400MHz to 5800MHz and is suitable for use in a variety of communication systems such as schools, broadcasting, and prisons. The amplifier module features a compact and lightweight design for easy installation and integration into a variety of systems.

Product Paramenters

NO	Item	Data	Unit	Notes
1	Frequency	400-5800	MHZ	Customized
2	Work Temperature	-20~+70	℃
3	Max Output Power	50	W
4	Work Voltage	DC28	V
5	Max Gain	47	dB
6	Flatness	±1	dB
7	Max Current	4	A
8	Output VSWR	≤1.5
9	Output Connector	SMA/F 50Ω		Customized
10	Power Amplifier Efficiency	45		when Max Output
11	Switch Control	high low level current	V	0V off /0.6 on
12	Standing Wave Protection	OK
13	Temperature Protection	75°	℃
14	Size	1795020	mm
15	Weight	0.294	Kg
