400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection 400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection 400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection 400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection

400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection

Product Details:
Place of Origin: Guangdong, China
Brand Name: flysafe
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Delivery Time: 7-15 work days
Payment Terms: LC,T/T
Contact Now

Detail Information
Frequency: 400-5800MHZ(Customized) Size: 179*50*20mm
Weight: 294g
Highlight:

5800MHz Signal Jammer Module

,

Power Amp Signal Jammer Module

,

400MHz power amp module

Product Description

400-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection

Product Description

This is a 400-5800MHz 50W amplifier module with temperature protection. This high performance 400-5800MHz 50W amplifier module is a cutting edge solution for enhancing signal strength in a variety of applications. The temperature protected 400-5800MHz 50W amplifier module has a frequency range of 400MHz to 5800MHz and is suitable for use in a variety of communication systems such as schools, broadcasting, and prisons. The amplifier module features a compact and lightweight design for easy installation and integration into a variety of systems.

Product Paramenters

NO
Item
Data
Unit
Notes
1
Frequency
400-5800
MHZ
Customized
2
Work Temperature
-20~+70
℃

3
Max Output Power
50
W

4
Work Voltage
DC28
V

5
Max Gain
47
dB

6
Flatness
±1
dB

7
Max Current
4
A

8
Output VSWR
≤1.5

9
Output Connector
SMA/F 50Ω

Customized
10
Power Amplifier Efficiency
45

when Max Output
11
Switch Control
high low
level current
V
0V off /0.6 on
12
Standing Wave Protection
OK

13
Temperature Protection
75°
℃

14
Size
179*50*20
mm

15
Weight
0.294
Kg


Details Images

400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection 0
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection 1
400MHz-5800MHz 50W Power Amp Signal Jammer Module With Temp Protection 2
